JA5-N2_108037
JA5-N2_108037
- 产品概述
- 规格参数
- 资料下载
⊙定电压输入，稳压输出Fixed input,Stabilivolt output
⊙转换效率Converter efficiency :70%
⊙开关频率Swiching frequency:100-200KHz±30KHz
⊙输入反向保护Input reverse protection
⊙输入与输出高隔离Input-output isolate
⊙PCB板上直插式安装Board in-line type installs
⊙温度适应范围宽Wide temperature range
⊙超薄SIP封装ultra-thin
⊙转换效率Converter efficiency :70%
⊙开关频率Swiching frequency:100-200KHz±30KHz
⊙输入反向保护Input reverse protection
⊙输入与输出高隔离Input-output isolate
⊙PCB板上直插式安装Board in-line type installs
⊙温度适应范围宽Wide temperature range
⊙超薄SIP封装ultra-thin
⊙封装尺寸Size dimensional：27.5x9.5x12.0mm
