J3QN_200100B1
- 产品概述
- 规格参数
- 资料下载
⊙定电压输入，方波输出Fixed input,Output normal square
⊙转换效率典型Typical efficiency :70%
⊙开关频率Swiching frequency:50-100KHz±30KHz
⊙无短路保护No short circuit protection
⊙输入与输出隔离Input-output isolate
⊙PCB板上直插式安装Board in-line type installs
⊙温度适应范围宽Wide temperature range
⊙六面金属屏蔽,超薄封装Six sides metal shielding,ultra-thin
⊙转换效率典型Typical efficiency :70%
⊙开关频率Swiching frequency:50-100KHz±30KHz
⊙无短路保护No short circuit protection
⊙输入与输出隔离Input-output isolate
⊙PCB板上直插式安装Board in-line type installs
⊙温度适应范围宽Wide temperature range
⊙六面金属屏蔽,超薄封装Six sides metal shielding,ultra-thin
⊙封装尺寸Size dimensional：50.8x25.4x12.7mm
